| Nama merek: | Copeland |
| Nomor Model: | D8SH-370X |
| Moq: | 1 |
| harga: | discussed |
| Waktu Pengiriman: | 1-7days |
| Ketentuan Pembayaran: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Jumlah silinder: | 8 | |
| Pemindahan [m³ / h ]: | 151 | |
| Berat badan [kg ]: | 351 | |
| Pengisian oli [dm³ ]: | 7,7 | |
| Max. operasi saat ini [A ]: | 64,5 | |
| Arus rotor terkunci [A ]: | 357 | |
| Catu daya [V / ~ / Hz ]: | 380-420V / 3 / 50Hz |
| milimeter | inci | ||
| Jalur hisap: | 2 5/8 " | ||
| Garis pembuangan: | 1 5/8 " |
Data teknis
| Jumlah silinder: | 8 | |
| Pemindahan [m³ / h]: | 151 | |
| Berat badan [kg]: | 347 | |
| Pengisian oli [dm³]: | 7,7 | |
| Max. operasi saat ini [A]: | 91,6 | |
| Arus rotor terkunci [A]: | 444 | |
| Catu daya [V / ~ / Hz]: | 400V / 3 / 50Hz |
| milimeter | inci | ||
| Jalur hisap: | 2 5/8 " | ||
| Garis pembuangan: | 1 5/8 " |
| tc t e | -35 | -30 | -25 | -20 | -15 | -10 | -5 |
| 30 | 24,08 | 32.02 | 41.35 | 52.17 | 64,57 | 78.65 | 94,48 |
| 35 | 21,87 | 29,71 | 38.92 | 49,59 | 61,80 | 75,65 | 91,24 |
| 40 | - | 27.10 | 36.17 | 46,67 | 58,68 | 72,29 | 87.61 |
| 45 | - | 24,17 | 33,08 | 43,38 | 55,17 | 68.54 | 83,56 |
| 50 | - | - | 29.61 | 39,70 | 51,26 | 64,35 | 79,08 |
| 55 | - | - | - | 35.60 | 46,90 | 59.71 | 74.11 |
| tc t e | -35 | -30 | -25 | -20 | -15 | -10 | -5 |
| 30 | 15,53 | 17,90 | 20.15 | 22,21 | 24,00 | 25,46 | 26,51 |
| 35 | 15.80 | 18,46 | 21,03 | 23,42 | 25,56 | 27,38 | 28,80 |
| 40 | - | 18,85 | 21,75 | 24,49 | 27,00 | 29,20 | 31,02 |
| 45 | - | 19,02 | 22.27 | 25,38 | 28.27 | 30,87 | 33.11 |
| 50 | - | - | 22,54 | 26.04 | 29,34 | 32,36 | 35,03 |
| 55 | - | - | - | 26,42 | 30.14 | 33.61 | 36,74 |
|
|
| Nama merek: | Copeland |
| Nomor Model: | D8SH-370X |
| Moq: | 1 |
| harga: | discussed |
| Rincian kemasan: | kemasan kayu |
| Ketentuan Pembayaran: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Jumlah silinder: | 8 | |
| Pemindahan [m³ / h ]: | 151 | |
| Berat badan [kg ]: | 351 | |
| Pengisian oli [dm³ ]: | 7,7 | |
| Max. operasi saat ini [A ]: | 64,5 | |
| Arus rotor terkunci [A ]: | 357 | |
| Catu daya [V / ~ / Hz ]: | 380-420V / 3 / 50Hz |
| milimeter | inci | ||
| Jalur hisap: | 2 5/8 " | ||
| Garis pembuangan: | 1 5/8 " |
Data teknis
| Jumlah silinder: | 8 | |
| Pemindahan [m³ / h]: | 151 | |
| Berat badan [kg]: | 347 | |
| Pengisian oli [dm³]: | 7,7 | |
| Max. operasi saat ini [A]: | 91,6 | |
| Arus rotor terkunci [A]: | 444 | |
| Catu daya [V / ~ / Hz]: | 400V / 3 / 50Hz |
| milimeter | inci | ||
| Jalur hisap: | 2 5/8 " | ||
| Garis pembuangan: | 1 5/8 " |
| tc t e | -35 | -30 | -25 | -20 | -15 | -10 | -5 |
| 30 | 24,08 | 32.02 | 41.35 | 52.17 | 64,57 | 78.65 | 94,48 |
| 35 | 21,87 | 29,71 | 38.92 | 49,59 | 61,80 | 75,65 | 91,24 |
| 40 | - | 27.10 | 36.17 | 46,67 | 58,68 | 72,29 | 87.61 |
| 45 | - | 24,17 | 33,08 | 43,38 | 55,17 | 68.54 | 83,56 |
| 50 | - | - | 29.61 | 39,70 | 51,26 | 64,35 | 79,08 |
| 55 | - | - | - | 35.60 | 46,90 | 59.71 | 74.11 |
| tc t e | -35 | -30 | -25 | -20 | -15 | -10 | -5 |
| 30 | 15,53 | 17,90 | 20.15 | 22,21 | 24,00 | 25,46 | 26,51 |
| 35 | 15.80 | 18,46 | 21,03 | 23,42 | 25,56 | 27,38 | 28,80 |
| 40 | - | 18,85 | 21,75 | 24,49 | 27,00 | 29,20 | 31,02 |
| 45 | - | 19,02 | 22.27 | 25,38 | 28.27 | 30,87 | 33.11 |
| 50 | - | - | 22,54 | 26.04 | 29,34 | 32,36 | 35,03 |
| 55 | - | - | - | 26,42 | 30.14 | 33.61 | 36,74 |
