| Nama merek: | Performer |
| Nomor Model: | SY380A4CBA |
| Moq: | 1pcs |
| harga: | discussed |
| Waktu Pengiriman: | 7-10 hari kerja setelah menerima pembayaran |
| Ketentuan Pembayaran: | L/C, T/T, Western Union |
50HZ / 380V / 3 Fase 31HP danfoss Scroll Variable Speed Compressor SY380A4CBA
Kompresor performer adalah jenis gulir kompresor yang digunakan untuk kedua 50Hz dan 60Hz,
Dapat digunakan untuk R22, R407c
Spesifikasi
1. Mengerjakan refrigeran R22
2. Daya Kuda: 31 HP
3. 50HZ / 380V / 3phase.
Seri SM:
SM084-4VM (7HP)
SM090-4VM (7.5HP)
SM100-4VM (8HP)
SM110-4VM (9HP)
SM115-4VM (9.5HP)
SM120-4VM (10HP)
SM125-4VM (10HP)
SM148-4VM (12HP)
SM160-4VM (13HP)
SM185-4VM (15HP)
SZ seires:
SZ084-4VM (7HP)
SZ090-4VM (8HP)
SZ100-4VM (8HP)
SZ110-4VM (9HP)
SZ120-4VM (10HP)
SZ148-4VM (12HP)
SZ161-4VM (13HP)
SZ / Y185-4VM (15HP)
Kami dapat menyediakan lebih banyak model kompresor seperti di bawah ini:
| Data 50Hz | |||||||||
| Model | Cap Nominal 60HZ | Kapasitas pendinginan nominal | Input daya | Polisi | EER | Volume menyapu | Pemindahan | Biaya minyak | |
| TR | W | Btu / h | KW | W / W | Btu / h / W | Cm / rew | M / h | Dm | |
| SM084 | 7 | 20400 | 69600 | 6.12 | 3.33 | 11.4 | 114.5 | 19.92 | 3.3 |
| SM090 | 7.5 | 21800 | 74400 | 6.54 | 3.33 | 11.4 | 120.5 | 20,97 | 3.3 |
| SM100 | 8 | 23100 | 79000 | 6.96 | 3.33 | 11.3 | 127.2 | 22.13 | 3.3 |
| SM110 | 9 | 25900 | 88600 | 7.82 | 3.32 | 11.3 | 144.2 | 25.09 | 3.3 |
| SM112 | 9.5 | 27600 | 94400 | 7.92 | 3.49 | 11.9 | 151.5 | 26.36 | 3.3 |
| SM115 | 9.5 | 28000 | 95600 | 8.31 | 3.37 | 11.5 | 155 | 26.97 | 3.8 |
| SM120 | 10 | 30100 | 102800 | 8.96 | 3.36 | 11.5 | 166.6 | 28.99 | 3.3 |
| SM124 | 10 | 31200 | 106300 | 8.75 | 3.56 | 12.2 | 169.5 | 29.5 | 3.3 |
| SM125 | 10 | 30100 | 102800 | 8.93 | 3.37 | 11.5 | 166.6 | 28.99 | 3.8 |
| SM147 | 12 | 36000 | 123000 | 10.08 | 3.58 | 12.2 | 193.5 | 33.7 | 3.3 |
| SM148 | 12 | 36100 | 123100 | 10.8 | 3.34 | 11.4 | 199 | 34.6 | 3.6 |
| SM160 | 13 | 39100 | 133500 | 11.6 | 3.37 | 11.5 | 216.6 | 37.69 | 4 |
| SM161 | 13 | 39000 | 133200 | 11.59 | 3.37 | 11.5 | 216.6 | 37.69 | 3.6 |
| SM175 | 14 | 42000 | 143400 | 12.46 | 3.37 | 11.5 | 233 | 40,54 | 6.2 |
| Model | Pendingin | Kekuasaan | Berat bersih |
| SZ100-3 / 9VM | R134A / R407C | 8HP | 72kg |
| SZ110-3 / 9Vm | 9HP | 72kg | |
| SZ120-3 / 9VM | 10HP | 80KG | |
| SZ125-3RM | 10HP | 80KG | |
| SZ148-3 / 9VAM | 12HP | 86KG | |
| SZ161-T3 / 9VC | 13HP | 86KG | |
| SZ / Y185-3 / 9CAM | 15HP | 103KG | |
| SZ240A3 / 9CBM | 20HP | 160KG | |
| SZ300A3 / 9CBM | 25HP | 160KG | |
| SM084-4VM | R22 | 7HP | 72kg |
| SM090-4VM | 7.5HP | 72kg | |
| SM100-4VM | 8HP | 72kg | |
| SM110-4VM | 9HP | 80KG | |
| SM112A4ACB | 9HP | 80KG | |
| SM115-4CAM | 9.5HP | 80KG | |
| SM120-4VM | 10HP | 80KG | |
| SM148-4VAM | 12HP | 86KG | |
| SM125-4CAM | 10HP | 80KG | |
| SM124A4ACB | 10HP | 80KG | |
| SM147A4ACB | 12HP | 86KG | |
| SM161-4VAM | 13HP | 86KG | |
| SM160-4CBM | 13HP | 93KG | |
| SM175-4CAM | 14HP | 103KG | |
| SM175-4RM | 14HP | 103KG | |
| SM185-4CAM | 15HP | 103KG | |
| SM185-4RM | 15HP | 103KG | |
| SY240A4CBM | 20HP | 160KG | |
| SY300ACBM | 25HP | 160KG | |
| SY300A4CAM | 25HP | 160KG | |
| SY380A4CBM | 31HP | 225KG |
