| Nama merek: | original |
| Nomor Model: | ts2 068Z400 |
| Moq: | 1pcs |
| harga: | discussed |
| Waktu Pengiriman: | 7-10 hari kerja setelah menerima pembayaran Anda |
| Ketentuan Pembayaran: | L/C, T/T, Western Union |
Spesifikasi:
1. Regriratant: R404A / R507 / R22 / R134a / R12 / R502
2.Thermostatic expansion valve mengatur aliran cairan refrigeran ke evaporator.
3. Aliran yang dikontrol oleh katup adalah bola lampu termal yang dilekatkan ke saluran isap di outlet evaporator.
4.The Bulb termal merasakan panas evaporator dan menyesuaikan katup untuk mengakui Cairan pendingin sesuai dengan beban pendingin.
| Katup TX | ||||
| Model Danfoss T2 & TE2 (dengan Unit Orifice yang dapat dipertukarkan) | ||||
| Nomor bagian | Pendingin | Model | Koneksi | Koneksi Equaliser |
| Rentang N: -40 ° sampai +10 ° C - tanpa MOP | ||||
| 068Z3400 | R404A / R507 | TS2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3403 | TES2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3206 | R22 | TX2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3209 | TEX2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3346 | R134a | TN2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3348 | TEN2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3202 | R12 | TF2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3204 | TEF2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3212 | R502 | TY2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3215 | TEY2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3414 | R404A / R507 | TS2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3415 | TES2 | 3/8 "Fl. X 1/2" ODF | EXT 1/4 "FL | |
| 068Z3281 | R22 | TX2 | 3/8 "Fl. X 1/2" ODF | INT. |
| 068Z3284 | TEX2 | 3/8 "Fl. X 1/2" ODF | EXT 1/4 "FL | |
| 068Z3383 | R134a | TN2 | 3/8 "Fl. X 1/2" ODF | INT. |
| 068Z3385 | TEN2 | 3/8 "Fl. X 1/2" ODF | EXT 1/4 "FL | |
| Rentang N: -40 ° sampai +10 ° C - dengan MOP | ||||
| 068Z3402 | R404A / R507 | TS2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3405 | TES2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3208 | R22 | TX2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3211 | TEX2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3347 | R134a | TN2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3349 | TEN2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| Rentang NM: -40 ° hingga -5 ° C - dengan MOP | ||||
| 068Z3225 | R22 | TEX2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL |
| Rentang NL: -40 ° sampai -15 ° C - dengan MOP | ||||
| 068Z3408 | R404A / R507 | TS2 3/8 "x 1/2" Fl. | INT | |
| 068Z3409 | TES2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3226 | R22 | TX2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3227 | TEX2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3369 | R134a | TN2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3370 | TEN2 | 3/8 "x 1/2" Fl. | EXT 1/4 " | |
| 068Z3430 | R404 | TES2 | 3/8 "Fl. X 1/2" ODF | EXT 1/4 "FL |
| Rentang B: -60 ° sampai -25 ° C - dengan MOP | ||||
| 068Z3410 | R404A | TS2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3411 | TES2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3232 | R502 | TY2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3233 | TEY | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3420 | R404 | TS2 | 3/8 "Fl. X 1/2" ODF INT | |
| Rentang B: -60 ° hingga -25 ° C - tanpa MOP | ||||
| 068Z3404 | R404A | TES2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL |
|
|
| Nama merek: | original |
| Nomor Model: | ts2 068Z400 |
| Moq: | 1pcs |
| harga: | discussed |
| Rincian kemasan: | Kotak karton |
| Ketentuan Pembayaran: | L/C, T/T, Western Union |
Spesifikasi:
1. Regriratant: R404A / R507 / R22 / R134a / R12 / R502
2.Thermostatic expansion valve mengatur aliran cairan refrigeran ke evaporator.
3. Aliran yang dikontrol oleh katup adalah bola lampu termal yang dilekatkan ke saluran isap di outlet evaporator.
4.The Bulb termal merasakan panas evaporator dan menyesuaikan katup untuk mengakui Cairan pendingin sesuai dengan beban pendingin.
| Katup TX | ||||
| Model Danfoss T2 & TE2 (dengan Unit Orifice yang dapat dipertukarkan) | ||||
| Nomor bagian | Pendingin | Model | Koneksi | Koneksi Equaliser |
| Rentang N: -40 ° sampai +10 ° C - tanpa MOP | ||||
| 068Z3400 | R404A / R507 | TS2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3403 | TES2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3206 | R22 | TX2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3209 | TEX2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3346 | R134a | TN2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3348 | TEN2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3202 | R12 | TF2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3204 | TEF2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3212 | R502 | TY2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3215 | TEY2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3414 | R404A / R507 | TS2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3415 | TES2 | 3/8 "Fl. X 1/2" ODF | EXT 1/4 "FL | |
| 068Z3281 | R22 | TX2 | 3/8 "Fl. X 1/2" ODF | INT. |
| 068Z3284 | TEX2 | 3/8 "Fl. X 1/2" ODF | EXT 1/4 "FL | |
| 068Z3383 | R134a | TN2 | 3/8 "Fl. X 1/2" ODF | INT. |
| 068Z3385 | TEN2 | 3/8 "Fl. X 1/2" ODF | EXT 1/4 "FL | |
| Rentang N: -40 ° sampai +10 ° C - dengan MOP | ||||
| 068Z3402 | R404A / R507 | TS2 | 3/8 "x 1/2" Fl. | INT. |
| 068Z3405 | TES2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3208 | R22 | TX2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3211 | TEX2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3347 | R134a | TN2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3349 | TEN2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| Rentang NM: -40 ° hingga -5 ° C - dengan MOP | ||||
| 068Z3225 | R22 | TEX2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL |
| Rentang NL: -40 ° sampai -15 ° C - dengan MOP | ||||
| 068Z3408 | R404A / R507 | TS2 3/8 "x 1/2" Fl. | INT | |
| 068Z3409 | TES2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3226 | R22 | TX2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3227 | TEX2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3369 | R134a | TN2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3370 | TEN2 | 3/8 "x 1/2" Fl. | EXT 1/4 " | |
| 068Z3430 | R404 | TES2 | 3/8 "Fl. X 1/2" ODF | EXT 1/4 "FL |
| Rentang B: -60 ° sampai -25 ° C - dengan MOP | ||||
| 068Z3410 | R404A | TS2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3411 | TES2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3232 | R502 | TY2 | 3/8 "x 1/2" Fl. | INT |
| 068Z3233 | TEY | 3/8 "x 1/2" Fl. | EXT 1/4 "FL | |
| 068Z3420 | R404 | TS2 | 3/8 "Fl. X 1/2" ODF INT | |
| Rentang B: -60 ° hingga -25 ° C - tanpa MOP | ||||
| 068Z3404 | R404A | TES2 | 3/8 "x 1/2" Fl. | EXT 1/4 "FL |
